Test Terminal Blocks NW 13 Way
Features
- Facilitates easy testing.
- Rugged construction.
- High electrical strength.
- Extended top transparent cover-optional.
- Housing : Phenolic moulding, Black.
- Top Cover : Phenolic moulding, Black. optional tranparant polycarbonate.
- Terminals, screws & links : Brass, Nickel plated.
- Rated voltage : 600 V max.
- Rated current : 50 A max.
NW13-FC-TC
NW13-FC
NW13 WAY
| TYPE | CODE | |
|---|---|---|
| 1 | 13-way front connected with black Cover. | NW13-FC-SC |
| 2 | 13-way front connected with transparent Cover. | NW13-FC-TC |
| 3 | 13-way back connected with black Cover. | NW13-BC-SC |
| 4 | 13-way back connected with transparent Cover. | NW13-BC-TC |
